- Water passages are 33% wider than stock for improved fluid flow.
- Radiator cores are thicker than stock, providing increased surface area and cooling.
- Rugged construction features aircraft quality aluminum for strength and durability.
- TIG welded tanks, furnace brazed aluminum cores.
- Billet filler necks assure leak-proof sealing.
- Beaded inlet/outlet hose connections for positive sealing.
- Direct fit design - no installation modifications required.
OEM Reference: 2GU-12460-01-00
| Overall Height |
11.38 |
| Overall Length |
18.54 |
| Tank Wall Thickness |
0.08 |
| Outlet |
0.75 |
| Rows |
2 |
| Inlet |
0.75 |
| Overall Width |
2.95 |
| Core Length |
8.19 |
| Core Height |
11.97 |
| Core Size |
8.19 x 11.97 |
| Core Thickness |
1.57 |
